IEP 7.5' x 10' Heavy-Duty Single Folding Security Gate (Galvanized Steel) - SSG1075
Details
IEP 7.5' x 10' Heavy-Duty Single Folding Security Gate (Galvanized Steel) - SSG1075
Illinois Engineered Products offers single, folding gates crafted from galvanized steel, ideal for securing docks, receiving areas, garages, and entrances or corridors. They can adjust to different widths, ensuring clear lines of sight and ventilation. With the ability to swivel up to 180 degrees, they can be easily retracted from openings. These flexible gates can be mounted on outdoor door frames, between posts or bollards, to pallet racks, against walls, or used with windows, all with an installation time of under 30 minutes.
Key Features:
- Finish: Galvanized And Powder Coat Colors Are Available
- Webbing: 3/8" x 3/4" 14-Gauge Steel
- Frame: 1 1-1/2" x 1 1/2" 12 Gauge Angle Iron
- Mounting Bracket: 2 1/2" x 7" Steel L-Bracket
- Locking Bar: 1 1-2" x 1 1/2" 12-Gauge Angle Iron
- Hasp: 3/16" Steel Welded To Frame With Padlock Not Included
- Drop & Support Pins: 5/8" Diameter And Welded To Frame
- Caster: 2" Steel Casters That Are Welded To Frame
- Rivets: 3/16" x 1/2" Steel
- Includes Center Web Drop Pin
Use Cases:
- Great for all high-traffic areas
- Fantastic option for securing large areas like hallways and buildings
- Best used for entryways, doors, and windows
Specifications:
- In-Use Width: 9' - 10'
- In-Use Height: 7'
- Stacked Height: 7' 6"
- Stacked Width: 15"
Installation Gallery
SKU | SSG1075 |
---|---|
Expanded Width | 9' - 10' |
Expanded Height | 7' |
Collapsed Height | 7' 6" |
Collapsed Width | 15" |
Security Level | Heavy-Duty |
Optional Colors | Almond, Black, Deck Red, Rain Forest, Safety Blue, Safety Red, Safety Yellow, Tower Gray, Walnut Brown, White |
Finish | Galvanized, Powder-Coated |
Features | Center Drop Pin |
Manufacturer | Illinois Engineered Products |
